Hoist pendant cables link a suspended push-button station to the crane or hoist control circuit. The electrical drawing defines the required cores and ratings; hanging length, movement, support and site conditions determine the mechanical requirements. Check the selected pendant control cable against its current datasheet before ordering.

Pendant Cable vs Festoon Cable: Different Routes

A pendant control cable carries the operator’s push-button commands to a crane or hoist control circuit. A festoon or reeling cable may serve the moving route along a bridge or trolley. When comparing a pendant cable vs festoon cable, start with function and path: one serves the operator station; the other follows equipment movement. Map each route and confirm support and movement requirements before choosing a model.

Heron’s crane cable overview shows the main cable groups. For pendant options, see Pendant Cable RVVG and Pendant Cable RVV2G. Confirm every model against its current product data and your project requirements. The image compares RVVG with one steel support wire and RVV2G with two; verify the exact construction and intended support arrangement in the current datasheet.

What to Check Before Choosing Hoist Pendant Cables

  • Control circuit: Share the wiring diagram or specify the required conductor/core count, conductor size, rated voltage, shielding and protective conductor where applicable.

  • Suspension and movement: Give the hanging length, distance the operator must move, movement frequency, cable path, support method and any strain-relief requirements. Confirm whether the selected model is designed for that arrangement.

  • Operating environment: State whether the installation is indoors or outdoors and identify relevant exposure such as temperature, oil, moisture, sunlight or abrasion. Check the selected cable’s datasheet for the actual sheath material and ratings.

  • Connections and installation: Confirm connector or termination details, available space, cable outside diameter limits and how the cores must be identified at the control station.

What to Include in a Hoist Pendant Cable Quote Request

Send the crane or hoist make and model, control drawing, required cable length, hanging and travel details, installation environment, connection requirements and quantity. A clear photo of the existing cable label or a relevant equipment drawing can help identify missing information. If any electrical or mechanical detail is not yet known, say so rather than guessing.

Need a model recommendation? Send your application details to Heron for a cable review and quotation. Final construction and suitability should be confirmed against the selected model’s current datasheet and the equipment specification.
