Crane Pendant Cables: Applications & Support Checks

Crane pendant cables for fixed and travelling control stations. Check routing, RVVG/RVV2G support wires and strain relief against the model datasheet first.

CRANE & HOIST CABLESCABLE BUYING GUIDES

heron-sh

6/25/20252 min read

Crane pendant cables RVVG and RVV2G with one and two steel support wires
Crane pendant cables RVVG and RVV2G with one and two steel support wires

Crane pendant cables connect a suspended push-button control station to a crane or hoist control circuit. Their application is defined by where the operator works, how the station is supported and where the cable hangs or moves. Start with that arrangement before comparing individual cable models.

This guide focuses on pendant control cable applications and support checks. Use the equipment drawing and the exact cable datasheet to confirm electrical ratings, dimensions and installation limits.

Three crane pendant cable applications to distinguish

A pendant station at a defined operating position

For a station suspended from a hoist or a fixed attachment point, identify the two cable terminations, hanging length and intended operator position. Confirm how the station and cable are supported and where strain relief is required. The support arrangement must follow the equipment design; electrical conductors should not be assumed to carry the station's mechanical load.

A station that travels with the operator

When the operator moves along the crane, show how the station and cable follow that movement. Mark any support trolley, suspension hardware and transition from a moving supply route to the final pendant drop. That drawing helps distinguish a hoist pendant cable from a separate festoon or reeling cable serving the bridge or trolley.

A control station near process equipment or outdoors

Record relevant exposure to oil, moisture, sunlight, temperature and nearby moving parts. These conditions must be checked against the offered model's documentation. A photograph, black sheath or the phrase "heavy duty" does not establish oil resistance, outdoor suitability or an allowable suspended length.

RVVG and RVV2G: confirm the support arrangement

Heron's illustrated RVVG pendant cable has one steel support wire; the illustrated RVV2G pendant cable has two. Treat the wire count as a construction detail to match to the equipment drawing, not as a general ranking of cable strength.

Ask how the support wires are terminated, what supports the control station and which installation limits apply to the exact construction. A support wire is not automatically rated lifting equipment. Confirm conductor configuration, voltage, bending limits and environmental suitability from the current model datasheet.

Send a route sketch alongside the control drawing

An electrical diagram identifies the control circuits. A route sketch answers a different set of questions: where does the pendant drop begin, where does it end, how far does the operator move, and where are the suspension and strain-relief points? Mark nearby edges, pinch points and places where the cable could rub or twist.

For a broader selection checklist, read Pendant Cable for Crane Control Systems. For crane travel routes, compare the crane cable range and the YFFB vs RVV gantry-crane guide.

Frequently asked questions

Can one cable be assumed to serve both the pendant drop and crane travel?

No. Identify each route and its support system separately. The equipment may use pendant, festoon and reeling cables for different duties within the same installation.

Does a second support wire confirm suitability for my crane?

No. Suitability depends on the exact construction, termination and equipment support arrangement, as well as the electrical and environmental requirements.

What should purchasing prepare after the application is defined?

Use the pendant cable in bulk RFQ checklist to agree on quantities, cut lengths, documents and delivery requirements. Send the drawing and route details to Heron for a model review and quotation.
